Shielded-Twisted-Pair Cable Model for Chafe Fault Detection via Time-Domain Reflectometry - Paperback

by Nasa Technical Reports Server (Ntrs) (Created by), Et Al (Created by), Stefan R. Schuet (Author)

This report details the development, verification, and validation of an innovative physics-based model of electrical signal propagation through shielded-twisted-pair cable, which is commonly found on aircraft and offers an ideal proving ground for detection of small holes in a shield well before catastrophic damage occurs. The accuracy of this model is verified through numerical electromagnetic simulations using a commercially available software tool. The model is shown to be representative of more realistic (analytically intractable) cable configurations as well. A probabilistic framework is developed for validating the model accuracy with reflectometry data obtained from real aircraft-grade cables chafed in the laboratory.
